KDCR Double automatic clipping machine

Price - On request

The KDCR double clipping machine has been specially designed for the production of natural casing ring products. The machine is ideal for clipping pork and beef casings in the caliber range up to 46+ mm. It also processes collagen, cellulose or artificial casing ring or stick products up to 50 mm in caliber easily and reliably.

Features and benefits
Cycle speed up to 130 servings/min.
Capacity of the magazine with a clip is enough for 3,500 sausages.
Two-handed operation increases safety during production.
Easy to use, easy to maintain and quiet.
Robust construction with modular design to meet customer requirements.
Easy to install thanks to the mobile support frame.
JBT TIPPER TIE PRoCARE system available.
Details
Application: meat and vegan products.
Pneumatic control.
Damage-free casing handling, casing tension and clip pressure are individually adjustable.
Smooth, sloped surfaces and easy access ensure fast, hygienic cleaning.
Meets all the requirements of EN13885.
Equipment options
Control by means of a hand crank.
Sheath tensioning device.
Thread dispenser for the production of ring products.
Clips on the spools.
Automatic machine for loops.
Pneumatic brake mechanism for sheaths.
Electric chain counter.

Brand

JBT TIPPER TIE
